Genset Diesel Fortis Power DP60P5S

Fortis Power Diesel Generator DP60P5S

Enquiry Compare

Description

Spesifikasi umum :

    • Frequency (Hz)                : 50
    • Prime power (KVA/KW)   : 60/48

Fitur standar :

    • Brand : Fortis Power
    • Mesin : Perkins
    • Alternator : Stamford
    • Sistem excitation : self-excited
    • Engine-mounted battery charging alternator
    • Alternator IP23 protection, Canopy IP54 protection, Control system
    • Stainless galvanized zinc plates with strong corrosion resistance
    • Vibration isolators between the engine/alternator and base frame
    • Integrated wiring design
    • Equipped with an industrial muffler
    • Ambient Temperature : -20 C to 50 C. The coolant heater is needed when the temperature is below 5 C.
    • 50 C Radiator
    • High water temperature protection
    • Low fuel level alarm
    • 3 pole circuit breaker and power loom
    • Neutral earth link
    • Coolant and lubricating oil
    • Drainage for fuel tank
    • Top lifting and wooden pallet frame for forklifts slots for 60 kVA and below
    • Steel base frame with top lifting and fork slots for 80 kVA to 200 kVA
    • Complete protection functions and safety labels

Optional features :

    • AMF controllers are optional for the generators standardized with Auto Gen controllers
    • AREP and PMG are optional
    • ATS (Automatic Transfer Switch)
    • Sockets
    • AMF controller
    • Water jacket preheater, oil heater and double air cleaner, etc
    • 4 pole circuit breaker
    • Automatic fueling system
    • Fuel level switch
    • Fuel transfer circuit

Keterangan tambahan :

    • Untuk pemesanan dan pertanyaan bisa klik “ENQUIRY” untuk informasi lebih lengkap
    • Harga dan stok dapat berubah sewaktu-waktu tanpa pemberitahuan

Spesifikasi

Engine
Model : 1103A-33TG2
No. of cylinders : 3
Bore x stroke (mm) : 105 * 127
Displacement (L) : 3.3
Engine Speed (rpm) : 1500
Rated Power (KW/BHP) : 54/72
Lubrication Oil (L) : CH4/15W40
Oil Capacity (L) : 7.9
Coolant Capacity (L) : 10.2
Governer Method : Mechanical
Alternator
Alternator Model : LSA42.3L9
No. of poles : 4
Insulation (Hz) : H
Voltage Regulation (%) : ±0.5
Excitation System : Brushless
Soundproof Sets
Length : 2200 mm
Width : 920 mm
Height : 1300 mm
Approx net weight (Kg) : 1450
Noise Level (dBA@7m) : 60
Open Sets
Model : DP60P5
Length : 1880
Width : 800
Height : 1380
Approx net weight (Kg) : 890
Fuel tank capacity : 220
